Key Advantage:
◇ Elegant & modern design
◇ Symmertrical light and asymmetrical light choice
◇ Available in multiple lumen choice
◇ Different installation ways for different poles
◇ Dark friendly,no up light
◇ Less glare design,more comfortable
Application:
◇ Residential areas
◇ Road and street lighting
◇ High way, Airport, Parking place
◇ Pathway & Pedestrains
◇ Smart city option
Light source | SMD LED Module |
Color temperature | 4000K as standard. Optional 2700K, 3000K & 5000K & 5700K. Amber LED available |
Color stability | 3 or 5 MacAdam steps for all standard LED colors |
Power (W) | 20-100W |
Luminous Flux(lm) | 2400-12500 lm |
Luminaire efficiency | 120-125 lm/w |
Lumen Maintenance (L70) | ≥ 100,000 hours |
Lumen Maintenance (L90B10) | ≥50,000 hours |
Constant lumen output (CLO) | as optional |
Optics Material | PC |
Optics Cover | Tempered Glass |
ULOR (%) | 0% |
Spigot diameter | 60 |
Control inputs | 0-10V / DALI as optional |
Eletrical class | class I / class II |
Color | RAL7024 as standard (RAL or AKZO Future colors available) |
IP rating | IP66 |
IK rating | IK08 |
Operating temperature range | -40°C<Ta≤50°C |
LED module thermal protection | as optional |
Driver thermal protection | yes |
Surge protection | 10KV / 20KV as optional |
Certifications | CE CB |
Material | ADC12 / Lower copper contents |
